HIK DS-2CE16D0T-IPF 2 MP Fixed Mini Bullet Camera
2 MP Fixed Mini Bullet Camera
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 2.8 mm, 3.6 mm fixed lens
- Up to 20 m IR distance for bright night imaging
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
- Water and dust resistant (IP66)
Available models:
DS-2CE16D0T-IPF(2.8mm)
DS-2CE16D0T-IPF(3.6mm)
Product Data
- Camera
- Image Sensor2 MP CMOS
- Signal SystemPAL/NTSC
- Resolution1920 (H) × 1080 (V)
-
Frame Rate
TVI: 1080 p @25 fps/30 fps
AHD: 1080 p@25 fps/30 fps
CVI: 1080 p@25 fps/30 fps
CVBS: PAL/NTSC
- Min. Illumination0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Lens2.8 mm, 3.6 mm Fixed Lens
-
Field of View
2.8 mm, horizontal FOV: 96.9°, vertical FOV: 52.8°, diagonal FOV: 115.6°
3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0°
- Lens MountM12
- Day & NightIR Cut Filter
- WDR (Wide Dynamic Range)Digital WDR
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
- Image
- Image ModeSTD/HIGH-SAT
- AGCYes
- Day/Night ModeAuto/Color/BW (Black and White)
- White BalanceAuto
- AE (Auto Exposure) ModeBLC;Global;DWDR
- Noise Reduction2D DNR
- LanguageEnglish
- FunctionSharpness;Smart IR;Mirror;Brightness
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- Operating Conditions-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Power Supply12 VDC ± 25%
- ConsumptionMax. 3.5 W
- Protection LevelIP66
- MaterialPlastic
- IR RangeUp to 20 m
- CommunicationHIKVISION-C
- Dimension? 70 mm × 153.6 mm (? 2.76" × 6.05")
- Approx. 145 g (0.32 lb.)
- Image Sensor2 MP CMOS
- Signal SystemPAL/NTSC
- Resolution1920 (H) × 1080 (V)
-
Frame Rate
TVI: 1080 p @25 fps/30 fps
AHD: 1080 p@25 fps/30 fps
CVI: 1080 p@25 fps/30 fps
CVBS: PAL/NTSC
- Min. Illumination0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Lens2.8 mm, 3.6 mm Fixed Lens
-
Field of View
2.8 mm, horizontal FOV: 96.9°, vertical FOV: 52.8°, diagonal FOV: 115.6°
3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0°
- Lens MountM12
- Day & NightIR Cut Filter
- WDR (Wide Dynamic Range)Digital WDR
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
- Image ModeSTD/HIGH-SAT
- AGCYes
- Day/Night ModeAuto/Color/BW (Black and White)
- White BalanceAuto
- AE (Auto Exposure) ModeBLC;Global;DWDR
- Noise Reduction2D DNR
- LanguageEnglish
- FunctionSharpness;Smart IR;Mirror;Brightness
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- Operating Conditions-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Power Supply12 VDC ± 25%
- ConsumptionMax. 3.5 W
- Protection LevelIP66
- MaterialPlastic
- IR RangeUp to 20 m
- CommunicationHIKVISION-C
- Dimension? 70 mm × 153.6 mm (? 2.76" × 6.05")
- Approx. 145 g (0.32 lb.)
