HIK DS-K3B631TX-BASE Fixed Base
Fixed Base
- Fixed base for DS-K3B631TX series
- -S for single lane with 2 pedestal , -M for extend more lanes for 1 pedestal.
Available models:
Add to Favorites
Add to Favorites
Product Data
- Camera
- Image Sensor1/3" Progressive Scan CMOS
- Max. Resolution2560 ℅ 1440
-
Min. Illumination
Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0 Lux with IR
- Shutter Speed1/3 s to 1/100,000 s
- Wide Dynamic Range120 dB
- Day & NightIR Cut Filter
- Angle AdjustmentPan: 0～ to 355～, tilt: 0～ to 70～, rotation: 0～ to 355～
- Lens
- Lens TypeVarifocal Lens, motoried lens, 2.8 to 12 mm
- Focal Length & FOV2.8 to 12 mm: horizontal FOV 102～ to 31～, vertical FOV 54～ to 17～, diagonal FOV 123～ to 35～
- Lens Mount?14
- Iris TypeFixed
- ApertureF1.6
- Illuminator
- IR Wavelength850 nm
- IR RangeUp to 30 m
- Video
-
Main Stream
50 Hz: 20 fps (2560 ℅ 1440)
25 fps (1920 ℅ 1080, 1280 ℅ 720)
60 Hz: 20 fps (2560 ℅ 1440)
30 fps (1920 ℅ 1080, 1280 ℅ 720)
-
Sub-Stream
50 Hz: 25 fps (1280 ℅ 720, 640 ℅ 480, 640 ℅ 360)
60 Hz: 30 fps (1280 ℅ 720, 640 ℅ 480, 640 ℅ 360)
-
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline Profile/Main Profile/High Profile
- H.265 TypeMain Profile
-
Region of Interest (ROI)
1 fixed region for main stream
- Audio
- Audio Compression -S: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC
- Audio Bit Rate-S: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC)
- Audio Sampling Rate-S: 8 kHz/16 kHz
- Environment Noise Filtering-S: Yes
- Network
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP?, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
-
Simultaneous Live View
Up to 6 channels
- APIOpen Network Video Interface, ISAPI
- User/HostUp to 32 users. 3 levels: administrator, operator and user
- Network StorageMicroSD/SDHC/SDXC card (256 GB) local storage
- ClientiVMS-4200, Hik-Connect
-
Web Browser
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
- Image
- Image SettingsSaturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
- Day/Night SwitchAuto, Schedule, Day, Night
- Image EnhancementBLC, 3D DNR
- Interface
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board StorageBuilt-in memory card slot, support microSD card, up to 256 GB
-
Audio
-S:
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 K次, interface type: non-equilibrium
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 次, interface type: non-equilibrium
-
Alarm
-S: 1 input,1 output, max. 12 VDC, 30 mA
- Reset KeyYes
- Event
- Basic Event Motion detection, video tampering alarm, exception
- LinkageUpload to FTP, notify surveillance center, send email, upload to memory card, trigger recording, trigger capture
- General
-
Power
12 VDC ㊣ 25%, 0.8 A, max. 10 W, ?5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.32 A to 0.2 A, max. 11.5 W
- Camera MaterialMetal
- Camera Dimension?141 mm ℅ 99.9 mm (?5.6" ℅ 3.9")
- Package Dimension140 mm ℅ 140 mm ℅ 154 mm (5.5" ℅ 5.5" ℅ 6.1")
- Camera WeightApprox. 820 g (1.8 lb.)
- With Package WeightApprox. 1200 g (2.6 lb.)
- Storage Conditions-30 ～C to 60 ～C (22 ～F to +140 ～F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions-30 ～C to 60 ～C (22 ～F to +140 ～F). Humidity 95% or less (non-condensing)
-
Language
English, Ukrainian
- General FunctionAnti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Approval
-
EMC
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2016);
KC (KN 32: 2015, KN 35: 2015)
-
Safety
UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
-
Environment
CE-RoHS (2011/65/EU);
WEEE (2012/19/EU);
Reach (Regulation (EC) No 1907/2006)
- Electrical Safety ProtectionIP67 (IEC 60529-2013), IK10 (IEC 62262:2002)
