HIK DS-D43Q80CA-1PHT,Outdoor 45?? cutting Angle, 8.0mm, 160*160mm

Product image 1

HIK DS-D43Q80CA-1PHT,Outdoor 45?? cutting Angle, 8.0mm, 160*160mm

HIK DS-D43Q80CA-1PHT,Outdoor 45?? cutting Angle, 8.0mm, 160*160mm

DS-D43Q80CA-1PHT,Outdoor 45° cutting Angle, 8.0mm, 160*160mm

  • The outdoor edge-cutting module adopts a 45 ° chamfering kit design, with a single light panel size of 160 mm x 160 mm. It can flexibly construct right angle LED display screens, cylindrical LED display screens, and can also splice curved LED display screens with arc length radius greater than 1.25 meters
  • The edge-cutting module can improve the obvious seams and black edges when using conventional modules to splice right angle screens, column screens, and curved screens. It provides better adapting to the environment and the external structure and usage requirements of buildings, and achieving arbitrary splicing from multiple angles
  • Realizing arbitrary splicing from multiple angles. After splicing, the display screen transits evenly, and the splicing display effect will be improved
  • The edge-cutting module is widely used for outdoor scenes such as stages, shopping malls, and technology exhibition halls, and is suitable for outdoor project such as naked eye 3D large screen splicing

Available models:

DS-D4380CA-1PHT，Outdoor cutting Angle

Data sheet

          • Cabinet
          • Pixel ConfigurationSMD Triad LED
          • Pixel Pitch CategoryP8
          • Pixel Pitch8 mm
          • Dimensions (W × H × D)160 mm × 160 mm x 23 mm
          • Resolution20 × 20
          • Pixel Density15625 dots/m²
          • Lamp Board HousingWith housing
          • Maintenance MethodBack maintenance
          • Protection LevelIP65 (Front)
          • Key Material
          • Lamp Encapsulation1921（Copper）
          • Control System

            DS-D42C08-H

            DS-D42C20-H

          • Display
          • White Balance Brightness4500cd/㎡
          • Color Temperature2000K～14000K adjustable
          • Viewing AngleHorizontal 160°, vertical 130°
          • Contrast Ratio≥ 3000:1
          • Color Uniformity≤ ± 0.003Cx，Cy
          • Brightness Uniformity≥ 95％
          • Processing Performance
          • Driving MethodConstant current driving
          • Frame Frequency50/60 Hz
          • Refresh RateUp to 3840 Hz
          • Grey Level13-15bit adjustable
          • Power
          • Power SupplyDC4.5V~5V
          • Max. Consumption≤615 W/m² (4500nits)
          • Average Consumption≤205 W/m² (4500nits)
          • Working Environment
          • Working Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
          • Working Humidity10%~90%RH（No condensation）
          • Storage Humidity10%~90%RH（No condensation）
          • Storage Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
          $3,500.00

          Original: $10,000.00

          -65%
          HIK DS-D43Q80CA-1PHT,Outdoor 45?? cutting Angle, 8.0mm, 160*160mm—

          $10,000.00

          $3,500.00

          Product Information

          Shipping & Returns

          Description

          DS-D43Q80CA-1PHT,Outdoor 45° cutting Angle, 8.0mm, 160*160mm

          • The outdoor edge-cutting module adopts a 45 ° chamfering kit design, with a single light panel size of 160 mm x 160 mm. It can flexibly construct right angle LED display screens, cylindrical LED display screens, and can also splice curved LED display screens with arc length radius greater than 1.25 meters
          • The edge-cutting module can improve the obvious seams and black edges when using conventional modules to splice right angle screens, column screens, and curved screens. It provides better adapting to the environment and the external structure and usage requirements of buildings, and achieving arbitrary splicing from multiple angles
          • Realizing arbitrary splicing from multiple angles. After splicing, the display screen transits evenly, and the splicing display effect will be improved
          • The edge-cutting module is widely used for outdoor scenes such as stages, shopping malls, and technology exhibition halls, and is suitable for outdoor project such as naked eye 3D large screen splicing

          Available models:

          DS-D4380CA-1PHT，Outdoor cutting Angle

          Data sheet

                  • Cabinet
                  • Pixel ConfigurationSMD Triad LED
                  • Pixel Pitch CategoryP8
                  • Pixel Pitch8 mm
                  • Dimensions (W × H × D)160 mm × 160 mm x 23 mm
                  • Resolution20 × 20
                  • Pixel Density15625 dots/m²
                  • Lamp Board HousingWith housing
                  • Maintenance MethodBack maintenance
                  • Protection LevelIP65 (Front)
                  • Key Material
                  • Lamp Encapsulation1921（Copper）
                  • Control System

                    DS-D42C08-H

                    DS-D42C20-H

                  • Display
                  • White Balance Brightness4500cd/㎡
                  • Color Temperature2000K～14000K adjustable
                  • Viewing AngleHorizontal 160°, vertical 130°
                  • Contrast Ratio≥ 3000:1
                  • Color Uniformity≤ ± 0.003Cx，Cy
                  • Brightness Uniformity≥ 95％
                  • Processing Performance
                  • Driving MethodConstant current driving
                  • Frame Frequency50/60 Hz
                  • Refresh RateUp to 3840 Hz
                  • Grey Level13-15bit adjustable
                  • Power
                  • Power SupplyDC4.5V~5V
                  • Max. Consumption≤615 W/m² (4500nits)
                  • Average Consumption≤205 W/m² (4500nits)
                  • Working Environment
                  • Working Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
                  • Working Humidity10%~90%RH（No condensation）
                  • Storage Humidity10%~90%RH（No condensation）
                  • Storage Temperature-20 ℃ to 60 ℃ (-4 ℉ to 140 ℉)
