86-inch 4K Interactive Display

• UHD 4K display with resolution of 3840 × 2160.
• Anti-glare and anti-blocking design to ensure smooth interaction.
• Dual systems of Android and Windows（Optional） saving cost and easy to use, video conference software are recommonded to run under Windows system.
• Quick response, at most 45-points touch control and smooth writing experience.
• Built-in network switch chip saves a network switch.
• All-in-one design with tempered glass and intelligent temperature control, making it environmental-friendly and safety-guaranteed, support blue light protection.

Data sheet

• Product Model
• Product ModelDS-D5C86RB/B

• Display
• Screen Size86 inch
• BacklightDLED
• Pixel Pitch0.1645（H）× 0.4935（V）mm
• Resolution3840 × 2160 @60 Hz
• Brightness400 cd/m² （Typ.）
• Color Depth10 bit
• Display Color1.07G
• Response Time6 ms
• Panel TypeVA
• Contrast Ratio

  5000:1 (Static)

  30,000:1 (Dynamic)

• Color Gamut72% NTSC（CIE1931）（Typ.）
• Refresh Rate60 Hz
• Viewing Angle178°(H)/178°(V)
• Aspect Ratio16:9
• Surface Hardness9H
• Surface Glass3.2 mm Anti-Glare Glass
• Surface Haze25%Haze
• Glass Bonding MethodZero Lamination
• Display Area1895.04mm ╳ 1065.96mm
• Working Duration7 × 16H
• Transmittance88% ± 3
• Lifespan50,000 hours

• Touch
• TypeInfrared Touch Screen
• Touch Point45 point multi-touch
• Touch Response Time＜ 5 ms
• Minimum Touch Object≥ 2 mm
• Touch Precision± 1 mm (≥ 90% touching area)
• Touch Resolution32768 × 32768

• Built-In System
• Operation SystemAndroid 13.0
• Memory8 GB
• Built-In Storage128 GB
• ProcessorQuad-core Cortex-A76 × 4（2.4GHz）and quad-core Cortex-A55 × 4（1.8GHz）
• GPUMali-G610 MC4
• HDCP Version2.3

• Camera
• PixelPixel 48MP for Photos & 8 MP for Video
• Camera FunctionSupport intelligent switching between Android system, OPS, and PC.
• Field Angle120°(diagonal), 110°(horizontal), 75°(vertical)
• Distortion≤2.5%
• Camera Resolution RatioUp to 4K

• Microphone
• SpecificationOmni-directional 8-array layout
• Mic FunctionEcho reduction and smart noise-cancellation
• Voice Distance12 m
• Sampling Rate32 K
• Mic Sampling Rate16 bit

• Internal Function
• LoudspeakerBuilt-in 2 ×20 W+25W loudspeaker;
• BluetoothBuilt-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.1
• NFCSupport screen mirroring by Android phones
• Light SensorYes
• Image Processing TechnologySupport 3D digital noise reduction, face detection, automatic white balance, automatic purple edge removal, automatic defogging；support shadow correction and distortion correction for lens.
• Audio Processing TechnologySupport dereverberation, adaptive noise reduction, adaptive non-stationary noise reduction, adaptive echo cancellation, automatic gain control, automatic electrical level control, sound source localization, speech dynamic detection, digital beam forming, speech detection.

• Interface
• Video & Audio InputHDMI In （HDMI 2.0）× 3, VGA In x 1, DP In （DP 1.2）× 1, Audio In × 1
• Video & Audio OutputHDMI Out （HDMI 2.0）× 1, Audio Out × 1, SPDIF Out × 1
• Control InterfaceTOUCH-USB 3.0 × 3, RS232 × 1
• Network Interface

  LAN (1000 Mbps) × 2

  WIFI AP&Station，2.4G/5G

  IEEE 802.11 a/b/g/n/ac  2x2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP

• Data Transmission InterfaceUSB 3.0 × 4, USB 2.0 × 1, Type-C × 2 (Type-C supports USB 2.0, DP 1.2, and charging functions; side charging 15 W, front charging 65 W)

• Power
• Power Supply100 to 240 VAC, 50/60 Hz
• Standby Consumption≤ 0.5 W
• Average Consumption< 205W

• General
• VESA800 mm × 600 mm （4 × M8-25 mm）
• Product Dimensions1960.5 mm × 1173.7 mm × 82.5 mm
• AccessoryWall mount bracket, hook, user manual, touch writing pen, packing list, 3M touch USB cable, 3M HDMI cable (2.0), 1.5m power cable (European standard), Bluetooth remote control.
• Package Dimensions (W × H × D)2197 mm × 284 mm × 1376mm
• Net Weight65.13 kg
• Gross Weight82.6 kg

• Working Environment
• Working Temperature0 °C to 40 °C (32 °F to 104°F)
• Working Humidity10%~90% RH
