Relay module

• 433 MHz two-way wireless communication
• AES-128 encryption
• LED display, show status of device and replay on/off display
• Small case design, which can be put into hiding places easily
• Automation operating, one button turn on/off from APP/Keyfob/Keypad
• Setting scenarios by different events
• An alarm input for tamper, NO, NC

Product Data

• Software features
• Scenario settingBy alarm, by operation, by fault, by schedule, by manual
• Learning button1, for register

• Hardware features
• Serial port1, for debug

• Electrical characteristics
• Power supplyDC 7V to 24V
• Operation humidity10% to 90%
• Operation temperature-10°C to 55°C

• Wireless transmission
• RF frequency433 MHz
• RF methodTwo-way communication
• RF modulation2GFSK
• RF distance800 m
• Wireless securityAES-128

• Display
• LEDs status3, register/signal (green/red), power (green), relay status (blue)

• General
• Installation methodWall-Mounting
• Dimension(WxHxD)38 mm × 25 mm × 18 mm
• Shell materialPlastic
• ColorWhite
• Weight28.5 g

• Device management
• Alarm input1 for tamper, NO/NC
• Relay output1, NO/NC (0 to 36V DC, Max 5A)
