HIK DS-TCG406-E 4 MP Access ANPR Camera

Product image 1

HIK DS-TCG406-E 4 MP Access ANPR Camera

HIK DS-TCG406-E 4 MP Access ANPR Camera

4 MP Access ANPR Camera

  • 1/1.8" progressive scan CMOS.
  • Up to 2688 × 1520 resolution with real-time video.
  • 4 built-in high-performance LEDs (integrated white light and IR).
  • 2.8 to 12 mm/8 to 32 mm motorized vari-focal lens.
  • Supports relay output to control vehicle barrier gate.
  • Supports Wiegand, connectable with access control system.
  • Supports loop triggering, radar triggering, and video triggering LPR.
  • Supports multi-frame LPR, improving LPR rate.
  • Supports dirty license plate recognition.
  • Equipped with vehicles passing detection algorithm to realize auto switch of barrier gate normally open mode during continuous vehicles passing and improve passing efficiency.
  • Supports vehicle type, vehicle color, and vehicle brand recognition.
  • Integrated shield, lights, and TF card slot (up to 1 TB).
  • Up to 100,000 blocklist and allowlist.
  • Supports offline control of barrier gate under allowlist mode.
  • Supports a variety of installation methods: pole mounting, wall mounting, pendant mounting, and universal joint installation. Equipped with concealed wire box.
  • Adopts entrance and exit dedicated exposure algorithm to adapt to the front/back light and inconsistent front and rear license plates scenes to improve LPR accuracy.

Available models:

DS-TCG406-E(12V/PoE)(0832)
DS-TCG406-E(12V/PoE)(2812)
DS-TCG406-E(12V/PoE/Y)(2812)
DS-TCG406-E(12V/PoE/Y)(0832)

Product Data

    • Camera
    • Max. Resolution2688 × 1520
    • Sensor Type1/1.8" Progressive Scan CMOS
    • Min. Illumination

      Color: 0.0005 Lux @ (F1.2, AGC ON)

      B/W: 0.0001 Lux @ (F1.2, AGC ON)

      0 Lux with IR

    • Shutter1/30 s to 1/100,000 s
    • Day/Night SwitchSupported
    • IR Cut Filter

      IR cut filter

      Blue glass module to reduce ghost phenomenon

    • Lens
    • Lens Type

      2.8 to 12 mm

      8 to 32 mm

    • Aperture

      2.8 to 12 mm: F1.2 to F2.5t

      8 to 32 mm: F1.7 to F1.73

    • Focal Length & FoV



      2.8 to 12 mm, horizontal FoV: 114.5° to 41.8°, vertical FoV: 59.3° to 23.6°, diagonal FoV: 141.1° to 48°,

      8 to 32 mm, horizontal FoV: 42.5° to 15.1°, vertical FoV: 23.3° to 8.64°, diagonal FoV: 49.6° to 17.3°

    • FocusAuto，Vari-focal lens, motor-driven lens
    • Supplement Light
    • Supplement Light TypeIR Light, Warm White Light
    • Supplement Light Range

      Video:

      2.8 mm to 12 mm: 25 m

      8 mm to 32 mm: 50 m

      Vehicle License Plate:

      2.8 mm to 12 mm: 10 m

      8 mm to 32 mm: 20 m

    • IR WavelengthWarm White Light 3000 K, IR Light 850 nm
    • Image
    • WDR140 dB
    • Main Stream

      50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

      60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

    • Sub-Stream

      50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

      60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)

    • Image Settings

      Saturation: 0 to 100

      Brightness: 0 to 100

      Contrast: 0 to 100

      Gain: 0 to 100

      3D DNR: Off, Normal, and Expert modes are selectable.

      White balance: White Balance 1 and White Balance 2 are selectable.

    • Image Parameters SwitchYes
    • WDR SwitchOn, Time, Brightness
    • Frame Rate25 fps (P)/30 fps (N)
    • Video
    • ROI8 regions respectively for main stream and sub-stream, 6 levels for each region.
    • Video Compression

      Main stream: H.265/H.264/MJPEG,

      Sub-stream: H.265/H.264/MJPEG,

    • H.264 Type

      Low profile

      Medium profile

      High Profile

    • Video Bit Rate32 Kbps to 16 Mbps
    • Bit Rate TypeConstant, Variable
    • Scalable Video Coding (SVC)H.265 and H.264 encoding
    • Capture Mode
    • Trigger TypeVideo Detection, I/O Coil, Radar Mixed Traffic
    • Picture TypeScene Picture, Scene Picture + Close-up Picture
    • Scene ModeEntrance & Exit Toll Gate, Underground Parking Entrance & Exit
    • Capture TypeStrobe Light Mode
    • Capture Parameters
    • Image FormatJPEG
    • Capture Resolution2688 × 1520
    • License Plate RecognitionForward, Backward, Bidirection
    • LED ControlSupports automatic light control/time control of LEDs
    • Smart RecognitionANPR, Motor Vehicle Feature, Vehicle Color Recognition, Enable Vehicle Manufacturer Recognition
    • Capture Picture OverlayLocation, Capture Time, Plate Number, Capture No., Vehicle Color Vehicle Type
    • Entrance and Exit
    • Barrier Gate Control ModeBy Camera/Platform/Mixed
    • Keep Boom Pole Open for Following VehicleEnable/Disable
    • Lock Barrier Gate for Large-Sized VehicleYes
    • Relay Output2-ch relay output, supporting opening and closing of barrier gates
    • Barrier Gate StatusNone, Barrier Gate Close In Place, Barrier Gate Open In Place, Remote Control Open In Place
    • Allowlist and Blocklist

      Up to 100,000 allowlist and blocklist totally

      Note: Only when the TF card is available, can the function take effect.

    • Network
    • Network StorageNAS (NFS, SMB/CIFS), auto network replenishment (ANR) together with high-end Hikvision memory card, memory card encryption and health detection are supported.
    • ProtocolTCP/IP, ICMP, HTTP, HTTPS, FTP Upload Picture, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SNMP, IGMP, QoS, IPv6, UDP, SSL/TLS, WebSocket
    • APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP, Otap, Guarding Vision Platform
    • ClientHik-Connect, Hik-Central，SDKdemo，PMS
    • Web BrowserPlug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+
    • SecurityPassword protection, complicated password, HTTPS encryption, watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
    • Interface
    • Audio1 input (line in), 1 output (line out)
    • Alarm Input3-ch triggered inputs
    • Alarm Output1-ch alarm output
    • WiegandSupported: CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit
    • RS-2321-ch RS-485 serial port
    • RS-4851-ch RS-232 serial port
    • Network Interface1 RJ45 10M/100M self-adaptive Ethernet port
    • Memory Card Slot1 TF card slot, up to 1 TB
    • Smart Function
    • LPR Accuracy

      Capture rate > 98%

      Vehicle moving direction recognition accuracy > 98.5%

      LPR accuracy > 98%

      Mistaken capture rate < 2%

      European and Russian-Speaking Regions:

      LPR accuracy > 98%

      Country/Region recognition accuracy > 95%

    • Vehicle Type RecognitionCar/Van/Bus/Truck/Light Truck/SUV_MPV/Pickup/Pedestrian/Motorcycle/Tricycle
    • Vehicle ColorRed, Yellow (including orange, golden), Green, Cyan, Blue, Purple, Pink, Brown, White, Gray (including silver), Black
    • Vehicle Brand84 manufacturers: Hyundai, Toyota, KIA, Honda, Volkswagen, Benz, Nissan, Ford, Isuzu, BMW, Chevrolet, Mitsubishi, Renault, Opel, Suzuki, Skoda, Daewoo, Audi, Mazda, GAC HINO, Peugeot, SsangYong, Citroen, Fiat, Scania, MAN, Volvo, Lexus, Seat, Land Rover, Daihatsu, Dongwo, Subaru, Iveco, MINI, JEEP, Porsche, Chery, Dodge, Chrysler, Acura, Alfa Romeo, Great Wall, Infiniti, Smart, Saic Maxus, JAC, Jaguar, GMC, Lincoln, JMC, SAAB, FAW, Yutong, Guangzhou Yunbao, Joylong, Geely, Cadillac, JBC, An‘kai, Haima, Foton, King Long, Dongfeng, Geely-Emgrand, Perodua, UD, BYD, Renault Samsung, Proton, HICOM, Malaysia_Unknown 1, Hyundai-Rohens, SsangYong-Old Version, Equus-Old Version, CNHTC, Rolls-Royce, Beiben Truck, Haval, Hino, Kia-Borrego, Chang‘an, Alfa, FORO
    • ANPR Supported Country/Region

      Middle East:

      The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain

      Africa:

      Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria

      Asia-Pacific:

      Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka

      America:

      Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala

      Europe:

      Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina

      Russian-Speaking Regions:

      Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan

    • Approval
    • EMC

      CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EEN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014);

      KC (KN 32: 2015, KN 35: 2015)

    • Security

      CB (IEC 62368-1: 2014 + A11);

      CE-LVD (EN 62368-1: 2014/A11: 2017);

      BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005);

    • EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
    • ProtectionIK10 (IEC 62262: 2002), IP67 (IEC 60529-2013)
    • General
    • Power Supply12 to 24 VDC/PoE (802.3at, 44 V to 57 V), 300 mA to 230 mA
    • Working Consumption10 W Max.
    • Dimensions415 mm × 145 mm × 145 mm (16.34 × 5.71 × 5.71 inch)
    • Weight3.25 kg (7.17 lb.)
    • Weight (with Package)4.3 kg (9.48 lb.)
    • Package Size465 mm × 200 mm × 198 mm (18.31 × 7.87 × 7.80 inch)
    • Storage Conditions

      Temperature: -20 °C to 70 °C (- 4°F to 158 °F)

      Humidity: 95% (non-condensing)

    • Startup and Operating Conditions

      Temperature: -30 °C to 70 °C (-22 °F to 158 °F)

      Humidity: 95% (non-condensing)

    • Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
