HW-NVR-N8208E-4K 8CH 2HDD 1U IntelliCore AI NETWORK VIDEO RECORDER
HW-NVR-N8208E-4K 8CH 2HDD 1U IntelliCore AI NETWORK VIDEO RECORDER Overview:
- ŸMax. 384Mbps incoming;
- ŸMax 8 Channel 8MP IPC input;
- ŸSupport ONVIF;
- Ÿ32-channel 1080P decoding capability;
- ŸSupports adaptive decoding
- ŸSupport 4K HDMI output;
- ŸUp to 16 channels for playback;
- ŸSupport P2P, APP Alarm Push;
- ŸSupport AI search;
- ŸAI by camera: Face Detection , Perimeter Protection, Object Detection,and AMD(Active Motion Detection£©
- ŸAI by record: Face Recognition, Face Detection, Perimeter Protection, AMD(Active Motion Detection£©
|
Technical Specifications |
|
|
System |
|
|
OS |
Embedded Linux |
|
OS Operation Interface |
Web/operating in local GUI |
|
Perimeter Protection by Camera |
|
|
Performance |
8 channels |
|
Face Detection by Camera |
|
|
Performance |
8 channels |
|
Object Detection by Camera |
|
|
Performance |
8 channels |
|
AMD by Camera |
|
|
Performance |
8 channels |
|
Perimeter Protection by NVR |
|
|
Performance |
4 channels |
|
Face Detection by NVR |
|
|
Performance |
4 channels |
|
Face Recognition by NVR |
|
|
Performance |
2 channels(20 face databases with 100,000 face pictures in total) |
|
AMD by NVR |
|
|
Performance |
8 channels |
|
Video&Audio Input |
|
|
Max bandwidth |
384Mbps |
|
IPC Input |
8CH |
|
Video & Audio Output |
|
|
VGA |
1920¡Á1080,1280¡Á1024,1280¡Á720 |
|
HDMI |
3840¡Á2160,1920¡Á1080,1280¡Á1024,1280¡Á720 |
|
Audio Output |
1CH, RCA (Line out,2Vp-p,300ohms) |
|
Audio Encoding |
|
|
Audio Compression |
G.711A |
|
Audio Bit Rate |
64Kbps |
|
Video Audio Decoding |
|
|
IP channel Resolution |
Up to 3840¡Á2160 |
|
Video decoding |
H.265£¨Main [email protected] High-tie£©/H.264 Up to High [email protected]£© |
|
Audio decoding |
G.711A, G711U, G726 |
|
Synchronous Playback |
8CH |
|
Decoding Ability |
8CH 4K@30FPS |
|
Preview |
|
|
Synchronous Preview |
8 |
|
Multi-screen Display |
1, 4, 8, 9 views |
|
Playback |
|
|
Record Mode |
Manual; Schedule (general; MD; alarm; intelligent) |
|
AI Search |
Search by target classification (human, vehicle, non-motor vehicle) |
|
Backup |
USB device |
|
? Playback Function |
1.Play; pause; stop; fast forward; fast backward; rewind; play by frame
2.Full screen; backup (cut/file) ; partially enlarge; audio on/off
|
|
Network |
|
|
? Network Protocol |
HTTP; TCP/IP; IPv4; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; P2P; Auto register |
|
Mobile Phone Access |
Android; iOS |
|
Interoperability |
ONVIF; SDK |
|
Browser |
IE; Edge; Google; Firefox |
|
HDD |
|
|
SATA |
2 |
|
ESATA |
1 |
|
Max Capacity |
16 TB |
|
External Interface |
|
|
PoE Ports |
0 |
|
Network Interface |
2 RJ-45( 10/100/1000 Mbps) |
|
VGA |
1 |
|
HDMI |
2 |
|
? USB |
2 USB 2.0 (on back panel)£¬2 USB 2.0+1 USB 3.0 (On front) |
|
RCA Input |
1 |
|
RCA Output |
2 |
|
Alarm Input |
16 |
|
Alarm Output |
8 |
|
RS-232? 1 |
|
|
RS-485? 1 |
|
|
Reset? 1(on the mainboard) |
|
|
Other Function |
|
|
IPC Access |
Support One-Click add IPC function |
|
Two-way Talk |
Yes |
|
Alarm Linkage |
Record; Snapshot; Buzzer; Log; Preset; Email |
|
Picture Capture |
Support JPEG Capture |
|
General Parameter |
|
|
Front Panel |
JS |
|
Packing |
405x365x123mm |
|
Dimensions |
1U 360x311.5x48mm |
|
Weight |
3Kg£¨No HDD£© |
|
Installation |
Desktop Installation |
|
Power Supply |
AC110V~220V¡À10%??? 47Hz¡«63Hz |
|
Working Temperature |
-10¡æ--£«55¡æ |
|
Working Humidity |
10£¥--90£¥ |
|
Consumption |
20W (without HDD,without POE) |
|
Certifications |
|
|
Certifications |
CE/FCC |
