HIK DS-PHA20-B Hybrid control panel PCB
Hybrid control panel PCB
- Hybrid System: 4 on-board zones , and 16 wired/wireless zones expadable
- 2 on-board outputs, and 18 wired/wireless outputs expadable
- Dual path communication of alarm events and other signals over LAN, PSTN, GPRS and 3G/4G utilizing a main and backup channel with configurable priority
- Supports 8 keyfobs, 9 keypads, 1 wired siren and 2 wireless sirens
- Supports arming/disarming via keypad, keyfob, mobile client, iVMS-4200, SMS, and tag
- Pushes alarm notification via messages and Hik-Connect
- Alarm video clips via emails and APP
- Supports ISAPI, Ehome 5.0, and DC09 protocol
- Uploads alarm events to alarm receiving center or platform
- 1 manufacturer, 1 installer, 1 administrator, and 13 Operators
Available models:
DS-PHA20-B
Product Data
- Software features
- Onboard real time video20
- Wi-Fi standardN/A
- Phone call notificationN/A
- Phone numbers8 (with GPRS/3G/4G module)
- SMS notificationsupport (with GPRS/3G/4G module)
- ScheduleAuto Arm/Disarm Schedule
- Wired network10M/100M Ethernet
- Wi-Fi encryptionN/A
- Configuration toolsWeb / iVMS-4200/Hik-Connect
- Firmware undate toolsWeb / iVMS-4200/Hik-Connect
- Cellular networkSupports report push- notification to ARC & Cloud (with 3G/4G/GPRS module)
- Exception detectionCommunication failure alarn, detection alarm
- ApplicationiVMS-4200 (client software) Hik-Connect (mobile client)
-
User
Installer: 1
Administrator: 1
Manufactuer:1
Operator: 13
- Area4
- Hardware features
- Serial portRS232
- Battery port/
- PSTN1, PSTN expander interface
- Tamper-ProofTampering alarm
- Netowrk interface1, RJ45 10M/100M Ethernet Interface
- BusRS485
- Electrical characteristics
- Battery typeLead-acid storage battery supported
- Power supply12VDC / Storage battery
- Operation humidity10% to 90%
- Operation temperature-10â‿to 55â‿(-4 °F to +122 °F)
- Battery life span16h (7Ah, standby mode)
- Wireless transmission
- RF frequency433MHz / 868MHz (with DS-PM-RSWR-433 / DS-PM-RSWR-868)
- RF distance/
- Display
- Indicator4 for status 1 for alarm
- General
- Dimension(WxHxD)/
- Application scenarioIndoor
- Shell materialN/A
- Color/
- Device management
- Tag12 (with DS-PK-LRT keypad)
-
Alarm output
2 on-board outputs, and 18 wired/wireless outputs
expadable
- Alarm input4 on-board zones , and 16 wired/wireless zones expadable
- Zones20
- Keypad9
- Sounder output1 wired siren (on-board connection) 2 wireless sirens
- Wireless sounder2
- Keyfob8
- Report method
- ProtocolISAPI: Supports client software and web client Cloud P2P: Supports cloud P2P privacy protocol DC09: ARC accessible (CID/SIA)
- Onboard real time video20
- Wi-Fi standardN/A
- Phone call notificationN/A
- Phone numbers8 (with GPRS/3G/4G module)
- SMS notificationsupport (with GPRS/3G/4G module)
- ScheduleAuto Arm/Disarm Schedule
- Wired network10M/100M Ethernet
- Wi-Fi encryptionN/A
- Configuration toolsWeb / iVMS-4200/Hik-Connect
- Firmware undate toolsWeb / iVMS-4200/Hik-Connect
- Cellular networkSupports report push- notification to ARC & Cloud (with 3G/4G/GPRS module)
- Exception detectionCommunication failure alarn, detection alarm
- ApplicationiVMS-4200 (client software) Hik-Connect (mobile client)
-
User
Installer: 1
Administrator: 1
Manufactuer:1
Operator: 13
- Area4
- Serial portRS232
- Battery port/
- PSTN1, PSTN expander interface
- Tamper-ProofTampering alarm
- Netowrk interface1, RJ45 10M/100M Ethernet Interface
- BusRS485
- Battery typeLead-acid storage battery supported
- Power supply12VDC / Storage battery
- Operation humidity10% to 90%
- Operation temperature-10â‿to 55â‿(-4 °F to +122 °F)
- Battery life span16h (7Ah, standby mode)
- RF frequency433MHz / 868MHz (with DS-PM-RSWR-433 / DS-PM-RSWR-868)
- RF distance/
- Indicator4 for status 1 for alarm
- Dimension(WxHxD)/
- Application scenarioIndoor
- Shell materialN/A
- Color/
- Tag12 (with DS-PK-LRT keypad)
-
Alarm output
2 on-board outputs, and 18 wired/wireless outputs
expadable
- Alarm input4 on-board zones , and 16 wired/wireless zones expadable
- Zones20
- Keypad9
- Sounder output1 wired siren (on-board connection) 2 wireless sirens
- Wireless sounder2
- Keyfob8
- ProtocolISAPI: Supports client software and web client Cloud P2P: Supports cloud P2P privacy protocol DC09: ARC accessible (CID/SIA)
