HIK DS-B31-12H24H B31 all-in-one controller
B31 all-in-one controller
- Adopts the 3 U standard rackmount chassis and ATCA chassis system for small to medium-sized surveillance.
- Adopts the plug-in modular design to provide flexible choice of model according to needs.
- Supports auto temperature adjustment of the intelligent fan to ensure system stability and reliability.
- Supports HDMI signal input and output.
- Supports the default H.264 encoding and H.265 encoding.
- Supports H.265, H.264, MJPEG and other mainstream encoding formats.
- Supports 12 channels of HD video encoding.
- Supports 192 channels of HD video decoding.
- Supports the maximum LED loading capacity of 2.3 MP per port.
- Supports 32 MP HD video decoding.
- Supports any splicing of 32 screens according to needs.
- Supports the division of 1, 4, 6, 8, 9, 16, and 25 per output port window.
- Supports opening a maximum of 384 windows on the video walls, opening a maximum of 3 layers on a single screen, and floating windows.
- Supports live view of video wall.
- Supports up to 128 preset scenes. The users can customize video wall layout of each scene.
- Supports up to 8 subtitles on the video walls and up to 3 subtitle on a single video wall.
- Supports the access and operation via the mobile client (Android or iOS), PC client, and Web client.
- Support using the ONVIF protocol to access devices for decoding.
Add to Favorites
Add to Favorites
View Less
View more
Available models:
DS-B31-12H24H
Data sheet
- Chassis
- Chassis Height3 U
- Bus TypeGigabit network switching
- Main Control Board Slot1
- Installed Main Control Boards1
- Power Supply Slot2
- Installed Power Supplies1
- Service Board Slot6
- Installed Service Boards4
- Device Decoding Capability192 channels of 1080p 30 fps
- Device Encoding Capability12 channels of 1080p 60 fps
- Device Splicing Capability24 channels
- Fan14 (2 fan boards, 7 fans per fan board)
- Interface
- USB Interface2 × USB 2.0
- Power
- Power Interface100 to 240 VAC, 50/60 Hz
- Device Consumption≤ 240 W
- Network
- Network Interface2 × 10/100/1000 Mbps self-adaptive Ethernet interface (RJ-45)
- Video Wall
- Video Walls8
- Video Wall Scale≤ 24
- Open Windows384
- Window Division per Screen1/4/6/8/9/16/25
- Input Source Copy CapabilitySupported
- Layers Per Screen3 × 1080p or 2 × 4K
- Layers per Device72
- Scenes128
- Signal Source Live ViewSupported
- Scene Auto-Switch Delay3 s
- Preview Channels2
- Preview ResolutionCIF(352 × 288)/QCIF(176 × 144)/HCIF(704 × 288)/DCIF(528 × 384)/FCIF(704 × 576)
- Background Image≤ 8, single background image resolution: 1280 × 720 to 7680 × 4320, background image format: JGP/JPEG.
- Subtitles≤ 8 subtitles on the video walls; ≤ 3 subtitles on a single video wall
- Input Image ClippingSupported, 200 pixels on the left, right, top and bottom edges.
- Delay of Displaying Local Signal Source on Video Wall120 ms
- Delay of Displaying Decoded Signal Source on Video Wall120 ms
- General
- Working Temperature0 °C to 50 °C
- Working Humidity10% to 90%
- Net Weight≤ 8.5 kg (18.74 lb.)
- Gross Weight≤ 16.7 kg (36.82 lb.)
- Dimensions (W × H × D)442.4 mm × 128 mm × 341.6 mm (17.42 inch × 5.04 inch × 13.45 inch)
- Packing List1 × serial port cable, 1 × AC power cord, 1 × power supply, 1 × grounding cable, 1 × M4 screw, 1 × HDMI bracket, several HDMI snap fittings, 1 × regulatory compliance and safety information manual
- Audio Input
- Audio Input Interfaces12
- Audio Input Interface TypeHDMI embedded
- Video Input
- Video Input Resolution1024 × 768@60 Hz, 1280 × 1024@60 Hz, 1366 × 768@60 Hz, 1440 × 900@60 Hz, 1680 × 1050@60 Hz, 1280 × 960@60 Hz, 1600 × 1200@60 Hz, 1280 × 720p@50 Hz, 1280 × 720p@60 Hz, 1920 × 1080p@50 Hz, 1920 × 1080p@60 Hz, 1920 × 1200@60 Hz, 3840 × 2160@30 Hz (only odd-numbered ports) Support custom input resolution, width and height range from 800 × 600 to 3840 × 2160, width 4 alignment, height 2 alignment
- Video Input Interface TypeHDMI 1.4
- Max. Video Input Resolution4K (Only odd-numbered ports)
- Video Input Interfaces12
- Video Encoding
- Video Encoding Channels12
- Video Encoding CapabilitySub-stream and main stream encoding; Sub-stream encoding contains: CIF(352 × 288)/FCIF(704 × 576), Main stream encoding contains: 720p(1280 × 720)/XVGA(1280 × 960)/ UXGA(1600 × 1200)/1080p(1920 × 1080)/XGA(1024 × 768)/ WXGA(1360 × 768)/SXGA(1280 × 1024)/SXGA(1400 × 1050)/ WSXGA(1440 × 900)/WSXGA+(1680 × 1050)/1920 × 1200/3840 × 2160
- Video Output
- Video Output Interface TypeHDMI 1.4
- Video Output Interfaces24
- Max. Video Output Resolution4K
- Video Output ResolutionXGA_60 Hz(1024 × 768@60 Hz)/SXGA_60 Hz(1280 × 1024@60 Hz)/ 720P_60 Hz(1280 × 720@60 Hz)/UXGA_60 Hz(1600 × 1200@60 Hz)/ WSXGA_60 Hz(1680 × 1050@60 Hz)/WUXGA_60 Hz(1920 × 1200@60 Hz)/ 1080P_60 Hz(1920 × 1080@60 Hz)/4K_30 Hz(3840 × 2160@30 Hz)
-
Loading Capacity for Video Output to LED
Single mesh port with load 2300000,
Width 288-3840;
Height 288-2160;
- Video Decoding
- Video Decoding FormatH.264, H.265, Smart264, Smart265, MJPEG
- Video Decoding Channels384
- Video Decoding CapabilityH.264/H.265/Smart264/Smart265 format: 12 channels of 32 MP/24 MP, 24 channels of 16 MP, 30 channels of 12 MP, 48 channels of 8 MP, 60 channels of 6 MP, 96 channels of 4 MP, 192 channels of 1080p, or 384 channels of 720p/D1 or lower resolution (One group of 4 outputs shares decoding capability) MJPEG format: 24 channels of 2 MP
- Audio Output
- Audio Output Interfaces24
- Audio Output Interface TypeHDMI embedded
- Encoding and Decoding/Audio Decoding
- Audio Decoding FormatG711-A, G711-U, G722.1, G726-16/U/A, MPG, AAC-LC
- Encoding and Decoding/Video Encoding
- Video Encoding FormatH.265(default) , H.264
- Control Interface
- Serial Interface1 × Console port (RJ-45) + 1 × reserved port for debugging + 2 × RS-485/RS-232 multiplex ports (RJ-45)
