HIK DS-C60S-04HO HDMI Output Board
HDMI Output Board
- The HDMI output board provides 4 HDMI ports and supports YUV 444 output.
- Supports HDMI composite audio output.
Available models:
Data sheet
- Chassis
- Occupied SlotOutput slot
- Video Output
- Video Output Interface TypeHDMI 1.4
- Video Output Interfaces4
- Max. Video Output Resolution1080P
-
Video Output Resolution
1920 × 1200@60 Hz, 1600 × 1200@60 Hz, 1920 × 1080@60 Hz, 1680 × 1050@60 Hz, 1280 × 720@60 Hz, 1280 × 1024@60 Hz, 1024 × 768@60 Hz
Supports LED screen, custom resolution output, 60 Hz loading output, and 2.6 MP loading with width ranging from 288 to 3840 and height ranging from 288 to 2160.
-
Loading Capacity for Video Output to LED
Single mesh port with load 2600000,
Width 288-3840;
Height 288-2160;
- Audio Output
- Audio Output Interface TypeHDMI composite audio
- Audio Output Interfaces4
