HIK DS-D42C08-H LED Controller
LED Controller
- 8 Gigabit Ethernet output ports, with up to 4096 × 2160@30 Hz signal input.
- Up to 3840 × 1080@60 Hz signal input. Point-to-point display for 8 network interfaces.
- Automatic source search: Enabled by default.
- 3D synchronized signal input and output interface: 3D signal accessible, 3840 × 1080@60 Hz input and output for each card.
- Audio device access: Audio device accessible, with audio input and output interfaces.
- Light sensor extension: Realize light sensor adjustment with no need to add a multi-functional card.
- Dual-mode remote control expansion interfaces: Infrared and USB RF Wi-Fi expansion interfaces, remote control enabled.
- Competent with load capacity: 5 MP.
- Cloud upgrade: Remote cloud online upgrade accessible.
- Strip display: Single line super long subtitle display with the content being left-justified, right-justified, centered, or scrolled.
- Scene management: Scenes customizable and switchable.
- Multi-controller cascade display realizes better synchronization.
- 3480 Hz high refresh rate and nanosecond response time ensure smooth video pictures.
Available models:
Data sheet
- Processing Performance
- Brightness Control1-100 Levels
- Frame Frequency25HZ-120HZ
- Grey Level1024
- Display Color1 Billion
- Processing Depth10bit
- Image ScalingSupport
- Product Model
- Product ModelDS-D42C08-H
- Chassis
- Chassis Height1U
- Chassis WidthFull Width
- Product Type
- Product TypeLED Controller
- LED Controller Power
- Average Consumption≤31W
- Number of power interfaces1
- Power interface specifications100～240 VAC, 50/60 Hz
- General
- Working Temperature0°C ~ 50°C
- Storage Humidity10% ～ 90%
- Working Humidity10% ～ 90%
- Storage Temperature-10°C ~ 50°C
- Packaging Size (W × H × D)538mmx261mmx118mm
- Net Weight2.4KG
- Gross Weight4.13KG
- Dimensions (W × H × D)440 mm × 200 mm × 44.5 mm
- Packing ListAC power cord*1, 1U chassis accessory kit*1, Manual*1, Foot pad assembly*1
- Audio Input
- Audio Input Interface(s)2
- Audio Input Interface Type1 HDMI inline + 1 line-in
- Video Input
- Video Input Interface(s)2
- Video Input Interface Type1 HDMI1.4 + 1 DVI (optional)
- Max. Input Resolution1080P
-
Video Input Resolution
Maximum supported resolution: 2048*1269@60Hz
Minimum supported resolution: 320*180@60Hz
Customizable resolution, total resolution not more than 260W@60
Limit width: 320~4096 Alignment: 4 alignment
Ultimate height: 180~4096 Alignment: 1 alignment
Support HDCP1.4
Does not support interlaced signal input
-
Video Input Processing Characteristics
Processing depth 8/10bit
Sampling format:
RGB:444
YUV:444
YUV:422
- Video Output
- Max. Output Resolution5.2 Million
-
Loading Capacity for Video Output to LED
Single mesh port with load 65W
Width 480~7680;Alignment: 2 Alignment
Height 270~4320;Alignment: 1 alignment
- LED Loading Interfaces8
- LED Loading Interface TypeRJ45
- Number of video ring pass output interfaces1
- Video looping output interface typeHDMI1.4
- Video looping output resolution2048*1269@60Hz
- Audio Output
- Audio Output Interface(s)2
- Audio Output Interface Type1 HDMI loop out +1 LINE OUT 3.5mm audio out
- Front Panel
- ScreenDigital Tube
-
Key
"\"+\"\": brightness increase
-\": brightness decrease
Source\": switch the signal source\""
-
pilot lamp
PWR: Power indicator
STAT:Status indicator
ASYNC: Internal Android source status light
SYNC: External source status light
- Control Interface
-
Control network port
2 RJ45, 10M/100M/1000M adaptive Ethernet ports
Used to connect to external networks, can support multi-device network cascade management
- 3D interface1 SYNC for 3D signal configuration, 3-Core S-terminal
-
IR input
1 x 3.5mm cradle
Support infrared remote control access
- Serial Interface1, 1 debug serial port (RJ45)
- Light perception1 light-sensitive aviation head
- USB2 x USB 2.0
- On-offSwitch
