HIK DS-PM1-I16O2-WE Multi IO transmitter
Multi IO transmitter
- 868MHz two-way wireless communication
- LED display, show the real status of device
- With 16 onboard inputs and 2 outputs, can be applied to connect wired detectors
- With two 12v power outputs, can be used to power up external wired detectors
- Large space for back up storage battery
Available models:
Product Data
- Software features
-
End of Line Resistance
1k 2.2k 4.7k 8.2k
NO/NC
- Hardware features
- Serial port1
- Battery port1, 12 VDC input
- Tamper-ProofFront and rear
- Power switch1
- Alarm input16
- Alarm output2
- Power Output2 (12v, total1A)
- Electrical characteristics
-
Battery type
Compatible with 12v 7 Ah
150 × 64 × 94 mm
- Power supply100-240VAC＿0w
- Operation humidity10%~90%
- Operation temperature‿0 ~ 40°C
-
Power consumption
Battery Supply: Quiescent current (50mA), Max current (1500mA), Voltage (13.8V)
220V Supply: Quiescent current (45mA), Max current (300mA), Voltage (220V)
- Battery life spanUp to 36 hours
- Wireless transmission
- RF frequency868MHz
- RF methodTwo-way communication
- RF modulation2GFSK
- RF distance1100m
- Display
- Indicator3: Power（Green＿ Fault（Amber＿ Signal Strength（Green/Red＿/span>
- General
- Installation methodWall Mounting
- Dimension(WxHxD)261*199*86.4mm
- Shell materialPlastic
- ColorWhite
-
975 g (without battery)
3024g (with battery)
-
End of Line Resistance
1k 2.2k 4.7k 8.2k
NO/NC
- Serial port1
- Battery port1, 12 VDC input
- Tamper-ProofFront and rear
- Power switch1
- Alarm input16
- Alarm output2
- Power Output2 (12v, total1A)
-
Battery type
Compatible with 12v 7 Ah
150 × 64 × 94 mm
- Power supply100-240VAC＿0w
- Operation humidity10%~90%
- Operation temperature‿0 ~ 40°C
-
Power consumption
Battery Supply: Quiescent current (50mA), Max current (1500mA), Voltage (13.8V)
220V Supply: Quiescent current (45mA), Max current (300mA), Voltage (220V)
- Battery life spanUp to 36 hours
- RF frequency868MHz
- RF methodTwo-way communication
- RF modulation2GFSK
- RF distance1100m
- Indicator3: Power（Green＿ Fault（Amber＿ Signal Strength（Green/Red＿/span>
- Installation methodWall Mounting
- Dimension(WxHxD)261*199*86.4mm
- Shell materialPlastic
- ColorWhite
-
975 g (without battery)
3024g (with battery)
