HIK DS-PM1-I8O2-H Wired Input Expande Cascade

Product image 1

HIK DS-PM1-I8O2-H Wired Input Expande Cascade

HIK DS-PM1-I8O2-H Wired Input Expande Cascade

Wired Input Expander（Cascade＿/span>

  • 8 on-board wired zones
  • Support 3EOL connection(Alarm＿KΩ；Tamper＿KΩ；Fault＿.2KΩ)
  • Support zone alarm，tamper，masking，fault，short detection
  • 1 power output for wired detectors
  • 2 Speed-X bus, supporting wired input expander cascade mode

Available models:

DS-PM1-I8O2-H



Product Data

  • Hardware features
  • Alarm input8
  • IO Output2 (connect to relay module)
  • Bus2×Speed-X bus, 1 input for control panel connection and 1 output for expander cascading
  • Tamper-ProofSupport (front and rear)
  • Electrical characteristics
  • Power supply11 to 24 VDC, 1A
  • Power consumption

    Maximum current 119 mA@12 VDC;

    Quiescent current 45 mA@12 VDC

  • Output Voltage11 to 24 VDC (Same voltage as power supply)
  • Output CurrentMaximum 500 mA
  • Display
  • LED IndicatorLED indicators＿ for power＿ for fault
  • General
  • Operation temperature -10°C to 40°C
  • Operation humidity10% to 90%
  • Shell materialPlastic
  • Dimension(WxHxD)110 mm × 155 mm × 32 mm
  • 252.5 g
  • Alarm input8
  • IO Output2 (connect to relay module)
  • Bus2×Speed-X bus, 1 input for control panel connection and 1 output for expander cascading
  • Tamper-ProofSupport (front and rear)
  • Power supply11 to 24 VDC, 1A
  • Power consumption

    Maximum current 119 mA@12 VDC;

    Quiescent current 45 mA@12 VDC

  • Output Voltage11 to 24 VDC (Same voltage as power supply)
  • Output CurrentMaximum 500 mA
  • LED IndicatorLED indicators＿ for power＿ for fault
  • Operation temperature -10°C to 40°C
  • Operation humidity10% to 90%
  • Shell materialPlastic
  • Dimension(WxHxD)110 mm × 155 mm × 32 mm
  • 252.5 g
$41.00
HIK DS-PM1-I8O2-H Wired Input Expande Cascade—
$41.00

Product Information

Shipping & Returns

Description

Wired Input Expander（Cascade＿/span>

  • 8 on-board wired zones
  • Support 3EOL connection(Alarm＿KΩ；Tamper＿KΩ；Fault＿.2KΩ)
  • Support zone alarm，tamper，masking，fault，short detection
  • 1 power output for wired detectors
  • 2 Speed-X bus, supporting wired input expander cascade mode

Available models:

DS-PM1-I8O2-H



Product Data

  • Hardware features
  • Alarm input8
  • IO Output2 (connect to relay module)
  • Bus2×Speed-X bus, 1 input for control panel connection and 1 output for expander cascading
  • Tamper-ProofSupport (front and rear)
  • Electrical characteristics
  • Power supply11 to 24 VDC, 1A
  • Power consumption

    Maximum current 119 mA@12 VDC;

    Quiescent current 45 mA@12 VDC

  • Output Voltage11 to 24 VDC (Same voltage as power supply)
  • Output CurrentMaximum 500 mA
  • Display
  • LED IndicatorLED indicators＿ for power＿ for fault
  • General
  • Operation temperature -10°C to 40°C
  • Operation humidity10% to 90%
  • Shell materialPlastic
  • Dimension(WxHxD)110 mm × 155 mm × 32 mm
  • 252.5 g
  • Alarm input8
  • IO Output2 (connect to relay module)
  • Bus2×Speed-X bus, 1 input for control panel connection and 1 output for expander cascading
  • Tamper-ProofSupport (front and rear)
  • Power supply11 to 24 VDC, 1A
  • Power consumption

    Maximum current 119 mA@12 VDC;

    Quiescent current 45 mA@12 VDC

  • Output Voltage11 to 24 VDC (Same voltage as power supply)
  • Output CurrentMaximum 500 mA
  • LED IndicatorLED indicators＿ for power＿ for fault
  • Operation temperature -10°C to 40°C
  • Operation humidity10% to 90%
  • Shell materialPlastic
  • Dimension(WxHxD)110 mm × 155 mm × 32 mm
  • 252.5 g
