HW-NVR-N6216E-L-4K 16CH 1U 2HDDs IntelliSight Network Video Recorder

HW-NVR-N6216E-L-4K 16CH 1U 2HDDs IntelliSight Network Video Recorder Overview:

lMax. 256 Mbps incoming; Max 16 Channel 8MP IPC input;

l16-channel 1080P decoding capability;

lSupports adaptive decoding;

lSupport 4K HDMI output ;

lUp to 16 channels for playback;

lSupport P2P, APP Alarm Push ;

lSupport AI search;

lAI by camera: Face Detection, Intrusion, Tripwire (classification of? human/vehicles /non-motor), Object Detection, and AMD

lAI by NVR: Face Detection, Intrusion, Tripwire (classification of? human/vehicles /non-motor), and AMD

Technical Specifications
System
OS	Embedded Linux
OS Operation Interface	Web/operating in local GUI
Perimeter Protection by Camera
Performance	16 channels
Face Detection by Camera
Performance	16 channels
Object Detection by Camera
Performance	16 channels
AMD by Camera
Performance	16 channels
Perimeter Protection by NVR
Performance	2 channels
Face Detection by NVR
Performance	2 channels
Face Recognition by NVR
Performance	NA
AMD by NVR
Performance	4 channels
Video&Audio Input
Incoming bandwidth	256Mbps
Output bandwidth	256Mbps
IPC Input	16CH
Video & Audio Output
VGA	1920¡Á1080,1280¡Á1024,1280¡Á720
HDMI	3840¡Á2160,1920¡Á1080,1280¡Á1024,1280¡Á720
Audio Output	1CH, RCA (Line out,2Vp-p,300ohms)
Audio Encoding

Audio Compression	G.711A
Audio Bit Rate	64Kbps
Video&Audio Decoding
IP channel Resolution	Up to 3840¡Á2160
Video decoding	H.265£¨Main [email protected] High-tie£©/H.264 Up to High [email protected]£©
Audio decoding	G.711A, G711U, G726
Synchronous Playback	16CH
Decoding Ability	16CH 1080P@30FPS/4CH 4K@30FPS
Preview
Synchronous Preview	16
Multi-screen Display	1, 4, 8, 9, 16 views
Playback
Record Mode	Manual; Schedule (general; MD; alarm; intelligent)
AI Search	Search by target classification (human, vehicle, non-motor vehicle)
Backup	USB device
? Playback Function	1.Play; pause; stop; fast forward; fast backward; rewind; play by frame 2.Full screen; backup (cut/file) ; partially enlarge; audio on/off
Network
? Network Protocol	HTTP; TCP/IP; IPv4; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; P2P; Auto register
Mobile Phone Access	Android; iOS
Interoperability	ONVIF; SDK
Browser	IE8 or later
HDD
SATA	2
ESATA	0
Max Capacity	14 TB
External Interface
PoE Ports	0
Network Interface	1 RJ45 1000M
VGA	1
HDMI	1
CVBS	0
USB	2 USB 2.0 (on back panel)£¬1 USB 3.0 (On front)
RCA Input	1
RCA Output	1
Alarm Input	0
Alarm Output	0

RS-232	0
RS-485	0
Other Function
IPC Access	Support One-Click add IPC function
Two-way Talk	Yes
Alarm Linkage	Record; Snapshot; Buzzer; Log; Preset; Email
Picture Capture	Support JPEG Capture
General Parameter
Front Panel	JS
Packing	405x365x123mm
Dimensions	1U 360x311.5x48mm
Weight	3Kg£¨No HDD£©
Installation	Desktop Installation
Power Supply	DC 12V 3A
Working Temperature	-10¡æ--£«55¡æ
Working Humidity	10£¥--90£¥
Consumption	20W(without HDD)
Certifications
Certifications	CE/FCC

**********
